KNIFE GATE VALVE MANUFACTURERS IN INDIA

0
649

Speciality Valve is one of the most prominent Knife Gate Valve Manufacturers in India and we are famous for providing high quality industrial valve that offer smooth flow control. We have years of experience and possess the necessary expertise in offering long lasting and high performance knife gate valve that suit the varied needs of many sectors.

Parts of Knife Gate Valve

  1. Body: Usually composed of stainless steel, cast iron, or ductile iron.
  2. Gate/Blade: The cutting-edge gate that slices through the media.
  3. Seat: Forms a snug seal and does not leak.
  4. Stem: Attaches the actuator to the gate.
  5. Actuator: May be manual, pneumatic, electric or hydraulic.
  6. Packing and Gland: Remains in place to avoid leakage around the stem area.

Working Mechanism

The valve works by raising or lowering the gate to manage the flow of the media. As the handwheel or actuator is rotated, the blade is driven vertically by the stem. The gate is lifted completely out of the flow path while in the open position. The blade cuts through the media and rests tightly on the seat when in the closed position, preventing flow entirely.

Advantages of Knife Gate Valve

  • Ideal for slurry, viscous, and corrosive fluid handling
  • Low-pressure drop when fully open
  • Compact and simple maintenance
  • Low cost for large diameter pipelines

Types of Knife Gate Valve

  1. Through Conduit Knife Gate Valve
  2. Uni Directional Knife Gate Valve
  3. Bi Directional Knife Gate Valve
  4. Slurry Knife Gate Valve
  5. Flanged Knife Gate Valve

Applications of of Knife Gate Valve

  1. Wastewater Treatment
  2. Mining
  3. Pulp and Paper
  4. Chemical Processing
  5. Power Generation
  6. Cement
  7. Agriculture
  8. Oil and Gas
  9. Marine and Offshore

Speciality Valve remains one of the most dependable Knife Gate Valves Manufacturers in India providing comprehensive valve solutions to meet industrial demand. Our focus on quality, performance and customer satisfaction guarantees that you only get the best flow control solutions.

Description

  • Available Materials: SS306, SS904, SS316, Aluminium Bronze, Monel, Bronze, Brass, Duplex steel, Inconel, Titanium, WCB, CF8, CF8M, CF3, CF3M, WC1, WC6, WC9, Cast iron
  • Size: 1/2″- 64”
  • Class: 150 to 2500
  • Nominal Pressure: PN10 to PN450
  • Operation: Hand Wheel, Gear operated, Electric and Pneumatic Actuated
  • Ends: Flanged, Wafer, Lug
  • Standards: ASME, API6D, API607, DIN, BS, ANSI, AWWA

Visit us: https://www.specialityvalve.com/product-category/knife-gate-valve/

ADDRESS - 37, NGR Street, P.N Palayam, Coimbatore, Tamil Nadu
